Viper 100 Series Applications
BLAC INC. Viper 100 Series Electric Actuators are engineered for precise valve control in process and oil & gas operations. Viper actuators have zero emissions, require minimal maintenance and deliver proven long-term reliable performance.
It is designed for linear applications up to 4 in (100 mm) stroke requiring high-level control. Viper 100 delivers exact control for most valve applications.
Viper applies the BLAC INC. patented hydraulic actuator cylinder rod seal to prevent contamination of the drive cylinder internals.
The Viper 100 Series uses absolute feedback positioning that enables the actuator to continuously maintain the commanded valve position. It incorporates a roller screw drive with servo design.
Viper 100 Series Download
Viper 100 Advantages
Electric Over Hydraulics/Pneumatics
Cost-Effective Control: Electric systems offer greater long-term savings for the desired control than alternatives.
High-Level Precision: Delivers exact control for most valve applications.
Simplified Integration: Integrated drive and controller precisely manages the motor speed and position.
Reduced Maintenance: Does not have the maintenance requirements of hydraulics or pneumatics.
Demand-Based Power: Reduced energy consumption.
Compact Design: Rugged, closed system.
Viper 100 Series electric actuator
mounted to valve yoke
Viper 100 Features
Precise modulating control with absolute position feedback
All-electric actuator without gears
Roller screw drive with servo design
Linear rising stem control valve actuators
On-Off applications
Fail in position with zero drift
Corrosion free construction materials of stainless steel and anodized aluminum
Mounts in place of a pneumatic or hydraulic cylinder
Performs equivalent to electro-hydraulic actuators
All worldwide electrical hazardous area classification
Viper 100 Series
mounted to valve yoke
(shown with electrical enclosure)
Viper 100 Data Sheet
| Item | Viper 100 Series Details |
|---|---|
| Command Signals | 4-20 mA, On-Off Digital |
| Feedback | Absolute position sensing |
| Rated Thrust | 1000 lbf (4448 N) |
| Seated Thrust ISO Rated Thrust |
1500 lbf (6672 N) |
| Stroking Speed | 1 in/sec (25.4 mm/sec) @ 24 VDC |
| Stroke Length | 4 in (101.6 mm) |
| Input Voltage | 12-24 VDC nominal, 9-32 VDC max range |
| Input Current | 10 A @ rated thrust, 1 A @ nominal thrust |
| Analog Input | One (1) isolated (4-20 mA, position/thrust demand) with 0.1% resolution, 0.5% linearity over temp range |
| Analog Output | One (1) isolated (4-20 mA, position/thrust feedback) with 0.1% resolution, 0.5% linearity over temp range |
| Digital Inputs | Three (3) isolated (9-30 VDC) |
| Digital Outputs | Two (2) isolated (9-30 VDC) |
| Operating Conditions | -40 to 149°F (-40 to 65°C) |
| Storage Conditions | -58 to 185°F (-50 to 85°C) |
| Enclosure Ratings | NEMA 4X, IP66 |
| Mounting | All orientations available |
| Serial Interface | Isolated Modbus RTU (RS-485), up to 38.4 k |
| Software Tool | Downloadable PC commissioning tool |
| Approvals | cCSAus Class 1, Division 2, Group A, B, C, D, T5 |
| Standards | ISO 22153, RoHS |
| Duty Class | Class D continuous modulating @ 100% duty cycle |
| Service Life | 10,000,000+ cycles over 10 years |
| Endurance | 10,000+ starts @ 3600 starts/hour |
